Product:Monghao MG-500 Series

Monghao MG-500 series is an all-posion automatic welding machine with wireless remote controller. The intelligent welding tractor can automaticlly welding around the pipeline, and realise all posions of the pipeline welding process (vercal welding, horizontal welding,overhead welding,downward, internal welding ect...). We provide one stop soluon with intelligent welding torch, unique magnet welding tractor, automatic wire feeder, power supply and wearing parts etc... The welding process is simply controlled by the hand-held wireless remote control, which can eﬃciently improve the welding quality at high producon rates even under severe environmental condions and reduce labor intensity. This welding equipment and method is widely used in ship building,bridges,locomoves, steel structure,petrochemical industry and other industries, suitable for a variety of welding structures.

PARAMETER

Pipe diameter	> 130mm
Tractor	magnetic wheel type tractor
Control mode	wireless remote control
Walking speed	0 - 1200mm / min
Welding torch swing parameters
Swing width	0.0 - 30.0 mm (left to right or right to left)
Swing frequency	0 - 200times/min
Duration of stay (left, right)	0.0 - 10.0s
Welding torch adjustment range	up/down 25 mm,forward / backward tilt 45°
Welding torch wire cable length	4.5m
Gas and Eletric cable length	15m
Shielding gas	CO2/MAG/MIG
Applicable wire	suggested solid wire Φ1.0mm or flux-cored wire Φ1.2mm,max wire diameter Φ1.6 mm
Remote control battery	lithium battery (360 hours lifetime)
Power Supply Rate	23.3/22.4KW
Power Supply Current	500A
Gross weight	140kg
Packaging size	820700820mm

Product specifification selection table

Model	Weldable material	Swing type	Can meet the welding position
MG-500plus	Carbon Steel	Horizontal Swing	1G/2G/3G/4G/5G
MG-500plus+	Carbon Steel	Horizontal Swing, Arc Swing	1G/2G/3G/4G/5G/6G
MG-500L plus+	Carbon Steel, Stainless Steel	Horizontal Swing, Arc Swing	1G/2G/3G/4G/5G/6G

It can be welded in trackless type or with rail type (Rail type is mainly used for welding large diameter pipe or non-magnetic adsorption pipeline).

Can match with flame cutting machine, plasma cutting machine etc.

Please consult sales for more details.

APPLICATION SCENARIO

Monghao has cooperated with nearly 2000 projects in chemical construction, oil pipeline, gas pipe, water pipeline, heating, air conditioning, railway, power construction, ships and other industries. Based on our rich experience in these industries, the All-position Automatic Pipeline Welding Machine launched by Monghao can meet high standard requirement of industry users.

CUSTOMER

We developed a new generation of all-position automatic welding machine system "Foxcweld", greatly improve the quality of welding and easy to operate.

Our welding machine can realise six axis action, which basically meets all the action needs of manual welding method.Workplaces applicability is wide and more than Φ130 mm pipes are applicable, without welding thickness limit. After preset parameters you can press the button to start.

We also open our welding expert system database to customers so they can develop the welding process on this platform independently,preset and real-time call parameters to keep seam formation consistency.
